Design with Big Impact!
The VSP-2 is Vertigo Sound's 3rd Big Impact Design and is setting a new benchmark in microphone amplification.
The heart of this unit is Vertigo Sound 100% discrete Twin Op Amp circuit called the OPA (operational amplifier) 1976.
These in-house stages are combined with Cinemags world famous CMMI-2C transformers to provide a smooth warm and defined sound from the lowest bass to the very top end of the sonic spectrum.The CMMI-2C transformer can handle very high input levels and provides a very linear phase behaviour because of low capacitance problems due to it`s low ratio of 1:2. Further the close ratio of the transformer forces the discrete OP Amp to provide most of the amplification in the VSP-2. This „full throttle“,“pedal to the floor“ circuitry enables a unique, rich, full and characterful sound.
The Discrete Op Amp 1976
99% of all newer designs use an I-ntegrated C-ircuit for this job which makes production easy and cost extensive.
Here‘s the big difference!
The Vertigo Sound 1976 is a fully discrete
DISCRETE OPERATIONAL AMPLIFIER
This very well thought out classic circuitry together with the Jensen JT16 transformer and Panasonic Coupling Caps plus the specific choice of components of the OP Amp gives you a fresh, punchy precise colourful sound without sounding dull or nasty at anytime.
Technical Specifications
- Dual Mono Mic pre with 1,5K input impedance
- Jensen Balanced In. That 1646 Balanced Out
- Dynamic Range: 116 db @ 36dB Gain
- Frequency response: 10 Hz … 35 kHz (+– 1db) @ 36dB Gain
- Max. Output Level: + 24 dBu / 600 Ohm balanced floating
- Noise: -81dBu (20 Hz – 22 kHz – unweighted, RMS) @ 36 db Gain
