Elysia Nvelope

Stereo Impulse Shaper

• Discrete class-A topology
• Full-range mode
• Dual band mode
• EQ mode
• Mixed mode
• Dual mono / Stereo link
• Auto gain
• Stepped potentiometer
• Frequency range: < 10 Hz - 400 kHz (-3 dB)
• A-weighted sound in full-range mode: 20 Hz - 20 kHz -3 dB
• A-weighted sound in dual band mode:
• 20 Hz - 20 kHz -87 dBu
• Dynamic range: 20 Hz - 22 kHz -3 dB
• Maximum level input / output: +21 dBu
• Input impedance: 10 kOhm
• Output impedance: 68 Ohm
• Made in Germany
• Robust but light housing made completely from aluminium
• In-/Outputs: XLR and jack
• Dimensions: 19", 1U
• Weight:
• 2 kg
